Tech
TALK Odor Control Dispersion Modeling:
Feeding the Data Monster
B y A d a m R o s e , PE , G I SP, PMP, A l a n P l u m m e r A s s o c i a t e s , I n c . ( APA I )
Dallas, Texas
Abstract Dispersion modeling has been used
to support wastewater treatment and
collection projects for a number of years.
Generating an atmospheric dispersion
model of an odor source requires a
great deal of input data: numerous
field samples, structure geometry and
processed terrain data to name a few.
This input data is typically processed
(via a dispersion model) through a high
volume of historical meteorological data
that then produces a large variety of
output scenarios. These scenarios aim to
present the broad range of atmospheric
conditions that may occur at any given
time, given the broad range of input
conditions that may also exist. Clearly,
this is a data-intensive process. For some
practical reasons, data collection, as well
as model calibration, have historically
been secondary to the development of the
model and results. This article discusses
ways to amass more data, using new and
non-traditional methods, for the collection
and calibration of dispersion models.
Background The topic of atmospheric dispersion
modeling is very broad. The following
sections aim to break down the topic into
a few core data requirements, describe
some traditional means and methods
of data collection, and then discuss
new features that may be helpful in the
ongoing field of dispersion modeling.
The goal of this article is to begin the
discussion of how technologies prevalent
in other fields may become useful support
tools for model development. Many of the
technologies discussed in this article exist
in some form in other sectors of society,
even in our daily lives.
32 july/august 2012
Model Building Needs
Atmospheric dispersion models are a
good decision support tool for odor control
planning, design and testing projects.
A valuable output of these models is an
estimate of the concentration of a given
chemical at a given time, location, duration
and initial/liquid or solid phase condition.
The number of different combinations of
input variables, which generate just a single
output value, is extensive (Table 1). The data
needs of the model correspond directly to the
number and type of required inputs, and can
also be quite extensive. In many instances the
Input Variable
Type Sampling Requirements
Note Odor Source
Source Concentration
Gas-phase samples of
odor generating locations
in the plant or system. a
Varies based on liquid phase
concentration, gas-liquid
boundary conditions, temperature,
wastewater characteristics, etc.
Defined by regulatory
requirements or project
experience. b
These typically only measured if
being used as part of calibration.
Temperature Atmospheric
Stability Relative
Humidity Wind Speed/
Direction Cloud Cover
Varies based on risk aversion.
Time Step
Time Duration
Elevation Terrain
Grid Size
Reflectivity Roughness
Defined by project
requirements. c
Stochastic models usually run
for one year to test for statistical
significance. Deterministic models
run over a short time period (1-6
hours) to test specific conditions.
Defined by project
requirements. d
Higher resolution produces
more results but requires more
processing time.
Typically defined by land
use May also be further refined by
direction from source.
Table 1 – Selected Data Needs for Dispersion Modeling
Each unit process may be highly spatially and temporally variable. Typically sampling attempts to detect the
worst case release condition (independent of atmospheric dispersion conditions).
b Previously generated datasets are typically used due to quality control standardization.
c A longer time step duration will lead to lower average dispersed concentrations due to meteorological variability.
Note that many modeling applications do not directly measure time steps shorter than 60 minutes – they infer
concentrations based on power law assumptions. The duration will correspond to the type of meteorological data.
d Most models produce results based on Cartesian or polar grids. The trade off in small grid size (keeping total
coverage area the same) is in computing time: even modern computers may require several hours to generate a
single, complex model run of several hundred receptors.
